Built for the way your line actually runs.
A fully automatic 2-cavity linear stretch blow moulding machine with an extended heating oven and long-stroke stretch rods, for 3L to 10L PET containers.
Standard 4- and 6-cavity linear blowers are optimised for 200ml to 2L. Above 3 litres the preform is heavier, needs longer and more evenly distributed heating, and requires a longer stretch stroke than those machines provide — pushing a 5L preform through a 4-cavity machine produces uneven wall thickness and a weak base. This machine is built for that range: fewer cavities, a longer multi-zone oven with independent lamp control, servo-driven long-stroke stretching, and a higher clamping force to hold the larger mould set. It is the standard companion to our 5L/10L home-pack filling line.
Who this configuration suits.
Get a detailed quote for the 2-Cavity Automatic Blower.
Layout drawing, utility schedule, BIS / FSSAI checklist, itemised quotation in 24 hours.
Everything we ship with this plant.
Standard turnkey scope. Optional add-ons quoted on request.
Specs at a glance.
| Output | 900 – 1,400 BPH (5L), 600 – 900 BPH (10L) |
| Cavities | 2 |
| Bottle range | 3L – 10L |
| Preform neck | 38mm – 55mm |
| Blowing pressure | 25 – 35 bar |
| Heating | Multi-zone IR with independent lamp control |
| Power load | 45 – 70 kW |
| Footprint | 350 – 550 sq.ft. |
| Air recovery | Standard, 25–35% HP air saving |
Price on Request.
Every plant is quoted against your capacity, feedwater analysis, plot and product mix. Send us those and you get an itemised proposal within 24 hours.
Output, degree of automation and whether you need redundancy on critical stations.
A high-TDS, iron-heavy or seasonal input changes the treatment train and its cost materially.
Machinery only, or turnkey with civil drawings, utilities, commissioning and BIS / FSSAI documentation.
Number of SKUs, bottle sizes and how fast you need to switch between them.
Common questions.
Why not use a 4-cavity machine for 5L bottles?+
Heating length and stretch stroke. A 4-cavity oven cannot heat a 5L preform evenly at production speed, and the shorter stretch rod leaves the base under-formed. The result is inconsistent wall thickness and bottles that fail top-load and drop tests.
Can it also run 2L bottles?+
Yes, with a mould and neck tooling change, though you will be running at 2 cavities where a 4-cavity machine would be more productive. Most plants keep this machine dedicated to large formats.
